Transport Protocol

TS over UDP/RTP, unicast and multicast,   IGMP V2/V3

Transmission Rate

Max 840Mbps for each GE input

Mux

Input Channel

1024

Output Channel

32

Max PIDs

256 per channel

Functions

PID remapping(auto/manually optional)

PCR accurate adjusting

PSI/SI table automatically generating

Scrambling

Parameters

Max simulscrypt CA

4

Scramble Standard

ETR289, ETSI 101 197, ETSI 103 197

Connection

Local/remote connection

Modulation

Parameters

DVB-C Modulator Sectioon

J.83A

Constellation : 16/32/64/128/256QAM

Bandwidth :8M

J.83B

Constellation : 64QAM/ 256QAM

Bandwidth :6M

QAM Channel

32 non-adjacent carrier

Modulation Standard

EN300 429/ITU-T J.83A/B(DVB-C)

Symbol Rate

5.0~7.0Msps, 1ksps stepping

Constellation

16, 32, 64 , 128, 256QAM

FEC

RS (204, 188)

RF Output

Interface

1 F typed output port for 32 carriers, 75Ω

RF Range

50~960MHz, 1kHz stepping

Output Level

-20dBm~+10dBm(87~117dbµV), 0.1dB stepping

MER

≥ 40dB

TS output

32 IP output over UDP/RTP/RTSP,   unicast/multicast, 2 (Data1& Data2) 100/1000M Ethernet Ports

System

Network management software (NMS)   supporting

General

Demission

420mm×440mm×44.5mm (WxLxH)

Temperature

0~45℃(operation), -20~80℃(storage)

Power Supply

AC 100V±10%, 50/60Hz or AC 220V±10%,   50/60Hz
