Specification
u Supports automatic EPON/GPON mode
switching
u Support HGU function
u Supports PPPoe/DHCP/static IP routing
mode and bridge mode
u Supports IPV4 and IPV6 dual mode
u Supports LIN IP and DHCP Server configuration
u Supports port mapping and loop detection
u Support Firewall function and ACL function
u Supports IGMP Snooping/Proxy multicast features
u Support one way CATV RF radio frequency (optional)
sports event | typology | Technical Parameters |
PON | Interface Type | No CATV SC/UPC With CATV SC/APC |
receiver sensitivity | ≤-27dBm |
| luminous power | +1~+4dBm |
transmission distance | 20Km |
operating wavelength | TX: 1310nm RX: 1490nm |
CATV (optional) | operating wavelength | 1550nm |
Input optical power | 0~-12dBm |
Optical reflection loss | ＞45dBm |
frequency range | 47-1006MHz |
flatness | ±1 dBm (47-1006 MHz) |
output level | ≥80dBuv |
Output Impedance | 75Ω |
AGC | 0~-12dBm |
Carrier-to-noise ratio | ≥51dB |
CTB | ≥65dB |
CSO | ≥62dB |
LAN | Interface Type | 1 Gigabit RJ45 port |
transfer mode | 10/100/1000 Adaptive |
Power supply related | connector | DC005 φ2.1mm |
input voltage | 12V0.5A |
power wastage | ≤4W |
Environment-related | operating temperature | 0~+50°C |
Operating humidity | 10~85% (non-condensing) |
Storage temperature | -30~+60℃ |
Size Weight | Product Size | 110*104*27.5 |
Package Size | 210*140*35 |
Net Weight | ≤0.2Kg |
total weight | ≤0.5Kg |
