Operating Wavelength

nm

1290

1310

1330

Input Power

dBm

-20

-

+6

Can   custom

Output Power

dBm

-1

-

8

Can   custom

Gain

dB

-

14

-

Can   custom

Noise Figure

dB

-

-

8

Output Power Stability

dB

-

-

±0.2

Input isolation

dB

40

-

-

Output isolation

dB

40

-

-

PDG

dB

-

-

1

Working Mode

AGC/APC/ACC

Operating Temperature

0

-

+55

°C

Storage Temperature

-40

-

+85

°C

Relative Humidity (non-condensation)

5

-

95

%

Dimensions

mm

130*100*15

-

5.0

-

V

Voltage

-

-

2

A

Current

-

-

10

W

Consumption

1

+5V

P

+5V

2

+5V

P

+5V

3

+5V

P

+5V

4

+5V

P

+5V

5

+5V

P

+5V

6

+5V

P

+5V

7

GND

P

Ground

8

GND

P

Ground

9

GND

P

Ground

10

GND

P

Ground

11

Reserved

F

NC

12

Output Reflection Alarm

O

LVTTL

Not Support

13

GND

P

Ground

14

RESET INPUT

I

LVTTL

RESET(Vil)

15

RXD

I

LVTTL

Serial Input

17

Pump Current Alarm

O

LVTTL

Not Support

18

SOA1 Input Loss Alarm

O

LVTTL

Input Power Alarm

19

GND

P

Ground

20

GND

P

Ground

21

Reserved

F

NC

22

Reserved

F

NC

23

Reserved

F

NC

24

Reserved

F

NC

25

GND

P

Ground

26

Reserved

F

NC

27

SOA2 Input Loss Alarm

O

LVTTL

(Single Channel SOA，no function)

28

GND

P

Ground

29

SOA2 Output Power Alarm

O

LVTTL

(Single Channel SOA，no function)

30

GND

P

Ground

31

GND

P

Ground

32

GND

P

Ground

33

Case Temperature Alarm

O

LVTTL

High Temperature Alarm

34

SOA1 Output Power Alarm

O

LVTTL

SOA1 Output Power Alarm

35

Pump Temperature Alarm

O

LVTTL

High Pump Temperature Alarm

36

Pin is absent

LVTTL

Polarization key

37

Amplifier Disable Input

I

LVTTL

Not Support

38

Output Power Mute Input

I

LVTTL

Not Support

39

Reserved

F

NC

40

Reserved

F

NC

41

GND

P

Ground

42

GND

P

Ground

43

GND

P

Ground

44

GND

P

Ground

45

+5V

P

+5V

46

+5V

P

+5V

47

+5V

P

+5V

48

+5V

P

+5V

49

+5V

P

+5V

50

+5V

P

+5V
