&0dBm~-18dBm(Digital signal?

AGC Control range

0dBm~-9dBm

optical reflection loss

＞45 dB

CTB(note)

≥65dB

Optical connector form

FC/APC or SC/APC or FC/PC or SC/PC

CSO(note)

≥62dB

Frequency Range

45~1006MHz

Host voltage

DC5V

In-band flatness

±1dB@45~1006MHz

Adapter voltage

AC90V ~145V&AC145V ~ 265V or custom

RF output reflection

≥16dB@ 47~550MH ;

≥14dB@1006MHz

Infeed voltage

DC5V

Gain adjustment range

0-18dB

Operating temperature

-20℃ ~+55℃

Output level

（78~80）dBuV(AGC:@-9~+0dBm?Pin=0dBm)

power

<1W

Output port number

1or 2

Product net size

129*79*26mm

RF output impedance

75Ω

Product net weight

0.17kg
