Optical Return Loss

＞45 dB

Bypass Wavelength

1310/1490nm/1270nm/1577

Optical connector form

FC/APC or SC/APC or FC/PC   or SC/PC

Responsively

≥0.9A/W

Frequency Range

47~1000MHz

Optical Fiber Type

Single Mode

In-band flatness

±1dB@45~1006MHz

RF Connector

F-female or F-male

RF output reflection

≥16dB@ 47~550MH ; ≥14dB@1006MHz

CNR

≥51dB

Output level

62dBuV@0dBm input power

CTB

≥65dB

Output port number

1

CSO

≥62dB

RF output impedance

75Ω

Product net size

72×68×25mm

Operating temperature

-20℃ ~+55℃

Product net weight

0.076kg
