Wavelength of Input Beam(nm)

1110~1650/1550nm

Input optical power(dBm)

-12~ 0dBm

Output Impedance of Radio Frequency(Ω)

75Ω

Type of Optical connector:

SC/APC or SC/UPC

Reflectional loss of light(dB)

>45

C/N:

≥51dB

C/CSO

≥62dB

C/CTB

≥65dB

Range of frequencies

47~1000MHZ

Inner flatness of band

±1.5dB

Output Return of Radio Frequency:

≥16dB

Weight of Product(g)

69g

Overall Dimension(mm)

78×70×20mm

Packing list

Main products

Instructions

Warranty cards(1 Year)
