Wavelength   of Input Beam(nm)

1310~1550/1550nm

Input optical power(dBm)

-12~   0dBm

Output   Impedance of Radio Frequency(Ω)

75Ω

Type   of Optical connector:

SC/APC   or SC/UPC

Reflectional   loss of light(dB)

>45

C/N:

≥51dB

C/CSO

≥62dB

C/CTB

≥65dB

Range of frequencies

47~1000MHZ

Inner   flatness of band

±1.5dB

Output Return   of Radio Frequency:

≥16dB

Weight   of Product(g)

25g

Overall   Dimension(mm)

55×55×15mm

Packing list

Main products

Instructions

Warranty cards(1   Year)
