Specification

Feature:

1. small size, light weight, high capacity, easy to installation;
2. Industry Standard User Interface, be made of high impact plastic;
3. UV resistant and weather proof;
4. Up to 6 drop cable;
5. 1 inlet port( for cables with max diameter 12mm), 6 outlet ports;
6. Wall mounting or pole mounting ;
7. Suitable for 6 pcs SC simplex adapters or  6pcs LC duplex adapters ;
8. Reasonable inner space design;
9. Protect optical fiber;
10. Realize FTTH(fiber to the desktop)system and provide users with optical access or data access;
11. Used in FTTH indoor application, home or work area;
12. ROHS compliance.

Specification:

Item	Characteristic
Dimension(L*W*H)	210x140x40mm
Cable Diameter(mm)	Φ 7~Φ 10
Adaptor	6XSC simplex,6X LC duplex
Color	white
Material	ABS
Net Weight	257g
Operation Temperature	-20oC to + 50oC
Cable Ports	1+4
Max Capacity of Splice	6(single fiber)
Protection Class	IP67

Order Information: HY?20?T?6B
