Specification
Feature
Ø Select internationally renowned brands of low noise pump lasers,It has low distortion, wide band, high output optical.
Ø Imported high-performance Erbium-doped fiber, high energy conversion 32-bit ARM processor, light control output accuracy of ±1dBm.
Ø Optical power receiving range -5dBm ~ +10dBm, optical power output 13~24dBm.
Ø All control circuits and devices use high-efficiency switching chips, and the overall power consumption is≤10W.
Ø External 9V power supply, power connector can select national standard
Ø Built-in lithium battery,to ensure equipment can go on work after power
Item
| Description | Value | Notes |
|
1 | Bandwidth | 1535 ~ 1565nm |
|
|
2 | Input Power Range | -5dBm~ +10dBm | Nominal input + 3 dBm |
|
3 | Output Power Range | （13~14）dBm |
|
|
4 | Output Power Stability | ±0.1dBm |
|
|
5 | Noise Figure | ≤5.0dB | @+0dBm input，λ=1550nm |
|
6 | Return | Input≥45dB |
|
|
Output≥45dB |
|
|
7 | Optical Connector Type | SC/APC（Standard）& FC/APC | Customizable |
|
8 | C/N | ≥50dB | Test condition：GT/T 184-2002 |
|
9 | C/CTB | ≥63dB |
|
10 | C/CSO | ≥63dB |
|
11 | Power Supply | DC 9V | External power supply |
|
12 | Power consumption | ≤10W |
|
|
13 | Operating Temperature | -5~+42℃ |
|
|
14 | Storage Temperature Range | -30~+70℃ |
|
|
15 | Humidity | 95%（non-condensing） |
|
|
16 | Size | 310(L)*243(W)*81(H)mm |
|
|
17 | Weight（with packing box） | 1.2Kg | Equipment & Power Supply |
|
