Grade

Parameter

U

P

A

Operating Wavelength(nm)

1310and 1550 dual window

Band width(nm)

±40

Return loss(dB)

≥50

Operating Temperature(?)

-40~+85

Typical Excess Loss(dB)

0.07

0.07

0.1

Insertion Loss(dB)

50/50

≤3.4

≤3.6

≤3.8

40/60

≤4.5/2.6

≤4.7/2.7

≤4.9/2.9

30/70

≤5.7/1.9

≤6.0/1.9

≤6.3/2.1

20/80

≤7.6/1.2

≤7.9/1.2

≤8.4/1.4

10/90

≤11.0/0.65

≤11.3/0.65

≤12.0/0.8

5/95

≤14.2/0.4

≤14.6/0.4

≤15.5/0.5

2/98

≤18.4/0.25

≤18.8/0.3

≤19.5/0.4

1/99

≤21.5/0.2

≤22.5/0.25

≤23.5/0.35

PDL(dB)

≤0.1

≤0.15

≤0.20

Other specification base on customer request

Package Specification

Configuration

1*2or2*2

Fiber Lead length

0.8M or base on customer request

Fiber Type

250μm bare fiber

900μm lose tube

900μm?2mm?3mm lose tube

Package Dimension

(ø*L)

Ø3.2mm*58mm

Ø3.2mm*62mm

90mm*20mm*9.6mm

90mm*20mm*9.6mm

80mm*100*9.5mm
